YOLO V7 vs V8 Comparison

Comparison Videos

Video 1: Performance Comparison

https://youtu.be/k1dOZFcLOek

Video 2: Detection Accuracy Test

https://youtu.be/tpOGDclq7KY

Video 3: Real-world Scenarios

https://youtu.be/u5qxN2ACEP4

Video 4: Speed Benchmark

https://youtu.be/85SH08jN4dY

Overview

This is a comprehensive comparison between YOLO v7 and v8, testing performance, accuracy, and speed across multiple real-world scenarios.

Model Information

πŸ”· YOLO V7

πŸ”Ά YOLO V8

Testing Environment

Component Specification
CPU Intel Core i7-9800X @ 3.80GHz
GPU NVIDIA RTX 4090

πŸ’» Source Code

πŸ“ Example 1: YOLOv8 Video Processing with Real-time Detection and FPS Display

🐍 yolov8_video_processor.py
"""
YOLOv8 Video Processing Script
Process videos with object detection and save annotated results
"""

import cv2
import time
from ultralytics import YOLO


def process_video(model, video_path, output_path):
    """
    Process video with YOLOv8 detection and save annotated results

    Args:
        model (YOLO): YOLO model instance
        video_path (str): Path to input video
        output_path (str): Path to save output video
    """
    # Open video capture
    cap = cv2.VideoCapture(video_path)

    # Get video properties
    width = int(cap.get(cv2.CAP_PROP_FRAME_WIDTH))
    height = int(cap.get(cv2.CAP_PROP_FRAME_HEIGHT))
    fps = int(cap.get(cv2.CAP_PROP_FPS))

    print(f"πŸ“Ή Video: {video_path}")
    print(f"   Resolution: {width}x{height}")
    print(f"   FPS: {fps}")

    # Create VideoWriter object to save annotated video
    fourcc = cv2.VideoWriter_fourcc(*'mp4v')
    out = cv2.VideoWriter(output_path, fourcc, fps, (width, height))

    frame_count = 0
    total_processing_time = 0

    while cap.isOpened():
        success, frame = cap.read()

        if success:
            # Measure processing time
            start_time = time.time()
            results = model(frame)
            end_time = time.time()

            processing_time = end_time - start_time
            fps_realtime = 1 / processing_time

            # Accumulate statistics
            frame_count += 1
            total_processing_time += processing_time

            # Visualize results on frame
            annotated_frame = results[0].plot()

            # Display metrics on frame
            text = f"Time: {processing_time:.3f}s | FPS: {fps_realtime:.1f}"
            cv2.putText(
                annotated_frame,
                text,
                (10, 30),
                cv2.FONT_HERSHEY_SIMPLEX,
                0.8,
                (0, 255, 0),
                2,
                cv2.LINE_AA
            )

            # Write annotated frame to output
            out.write(annotated_frame)

            # Optional: Display real-time preview
            # cv2.imshow("YOLOv8 Detection", annotated_frame)
            # if cv2.waitKey(1) & 0xFF == ord("q"):
            #     break
        else:
            break

    # Cleanup
    cap.release()
    out.release()

    # Print summary statistics
    avg_fps = frame_count / total_processing_time if total_processing_time > 0 else 0
    print(f"βœ… Processed {frame_count} frames")
    print(f"   Average FPS: {avg_fps:.2f}")
    print(f"   Saved to: {output_path}\n")


def main():
    """Main function to process multiple videos"""

    print("=" * 60)
    print("πŸš€ YOLOv8 Video Processing Pipeline")
    print("=" * 60 + "\n")

    # Load YOLOv8 model
    print("πŸ“¦ Loading YOLOv8 model...")
    model = YOLO('yolov8x.pt')
    print("βœ… Model loaded successfully!\n")

    # List of video files to process
    video_paths = [
        "../video/videoplayback-1.mp4",
        "../video/videoplayback-2.mp4",
        "../video/videoplayback-3.mp4",
        "../video/videoplayback-4.mp4",
    ]

    # Process each video
    total_videos = len(video_paths)
    for i, video_path in enumerate(video_paths, 1):
        output_path = f"../video/yolo_v8_output_{i}.mp4"

        print(f"[{i}/{total_videos}] Processing video...")
        process_video(model, video_path, output_path)

    cv2.destroyAllWindows()

    print("=" * 60)
    print("πŸŽ‰ All videos processed successfully!")
    print("=" * 60)


if __name__ == '__main__':
    main()

πŸ“ Example 2: Combine Two Videos Side-by-Side for V7 vs V8 Comparison

🐍 combine_videos_comparison.py
"""
Side-by-Side Video Comparison Tool
Combine YOLOv7 and YOLOv8 results for visual comparison
"""

import cv2
import numpy as np


def combine_videos_side_by_side(video1_path, video2_path, output_path,
                                 label1="YOLOv7", label2="YOLOv8"):
    """
    Combine two videos side by side for comparison

    Args:
        video1_path (str): Path to first video (e.g., YOLOv7 results)
        video2_path (str): Path to second video (e.g., YOLOv8 results)
        output_path (str): Path to save combined video
        label1 (str): Label for first video
        label2 (str): Label for second video
    """
    # Open video captures
    cap1 = cv2.VideoCapture(video1_path)
    cap2 = cv2.VideoCapture(video2_path)

    # Get video properties
    width = int(cap1.get(cv2.CAP_PROP_FRAME_WIDTH))
    height = int(cap1.get(cv2.CAP_PROP_FRAME_HEIGHT))
    fps = int(cap1.get(cv2.CAP_PROP_FPS))

    print(f"πŸ“Ή Combining videos:")
    print(f"   Video 1: {video1_path}")
    print(f"   Video 2: {video2_path}")
    print(f"   Output size: {width * 2}x{height}")

    # Create VideoWriter for combined output (double width)
    fourcc = cv2.VideoWriter_fourcc(*'mp4v')
    out = cv2.VideoWriter(output_path, fourcc, fps, (width * 2, height))

    frame_count = 0

    while True:
        ret1, frame1 = cap1.read()
        ret2, frame2 = cap2.read()

        if not ret1 or not ret2:
            break

        # Combine frames horizontally
        combined_frame = np.hstack((frame1, frame2))

        # Add labels with background for better visibility
        # Label 1 (left side)
        cv2.rectangle(combined_frame, (5, 5), (200, 45), (0, 0, 0), -1)
        cv2.putText(
            combined_frame,
            label1,
            (10, 35),
            cv2.FONT_HERSHEY_SIMPLEX,
            1.2,
            (0, 255, 0),
            2,
            cv2.LINE_AA
        )

        # Label 2 (right side)
        cv2.rectangle(combined_frame, (width + 5, 5), (width + 200, 45), (0, 0, 0), -1)
        cv2.putText(
            combined_frame,
            label2,
            (width + 10, 35),
            cv2.FONT_HERSHEY_SIMPLEX,
            1.2,
            (255, 0, 0),
            2,
            cv2.LINE_AA
        )

        # Add divider line
        cv2.line(
            combined_frame,
            (width, 0),
            (width, height),
            (255, 255, 255),
            2
        )

        out.write(combined_frame)
        frame_count += 1

        # Optional: show progress every 100 frames
        if frame_count % 100 == 0:
            print(f"   Processed {frame_count} frames...")

    # Cleanup
    cap1.release()
    cap2.release()
    out.release()

    print(f"βœ… Combined {frame_count} frames")
    print(f"   Saved to: {output_path}\n")


def main():
    """Main function to create comparison videos"""

    print("=" * 60)
    print("🎬 Video Comparison Tool - YOLOv7 vs YOLOv8")
    print("=" * 60 + "\n")

    # Define video pairs to compare
    comparisons = [
        {
            'v7': "../video/yolo_v7_output_1.mp4",
            'v8': "../video/yolo_v8_output_1.mp4",
            'output': "../video/comparison_v7_vs_v8_test1.mp4"
        },
        {
            'v7': "../video/yolo_v7_output_2.mp4",
            'v8': "../video/yolo_v8_output_2.mp4",
            'output': "../video/comparison_v7_vs_v8_test2.mp4"
        },
    ]

    # Process each comparison
    for i, comp in enumerate(comparisons, 1):
        print(f"[{i}/{len(comparisons)}] Creating comparison video...")
        combine_videos_side_by_side(
            comp['v7'],
            comp['v8'],
            comp['output'],
            label1="YOLOv7",
            label2="YOLOv8"
        )

    print("=" * 60)
    print("πŸŽ‰ All comparison videos created successfully!")
    print("=" * 60)


if __name__ == '__main__':
    main()

Key Features

  • βœ… Real-time FPS display on processed videos
  • βœ… Batch processing for multiple videos
  • βœ… Side-by-side comparison visualization
  • βœ… Progress tracking and statistics
  • βœ… Clean, well-documented code

Comparison Metrics

  • πŸš€ Speed: Inference time and FPS performance
  • 🎯 Accuracy: Detection precision and recall
  • πŸ“¦ Model Size: yolov7x.pt vs yolov8x.pt
  • πŸ’‘ Ease of Use: API and implementation differences
  • 🌍 Real-world Performance: Various scenarios tested

Resources

Thank you! 😺
